Huawei WiFi Mesh X3 Pro Suite
$299.00
Choose your color
6 Month Warranty
SPECIFICATION
Master router
:
Height : 250.9 mm
:
Diameter : 123.2 mm
Extender
:
Height : 73.5 mm
:
Diameter : 114.8 mm
Master router weight
:
About 790 g
Extender weight
:
About 420 g
Wireless Band
:
2.4 GHz & 5 GHz (Support dual band integration configuration)
Transmission Standard
:
IEEE 802.11be/ax/ac/n/a, 2 × 2 MIMO
:
IEEE 802.11be/ax/n/g/b, 2 × 2 MIMO
:
2 × 2 MU-MIMO : Supported
Wireless Transmission Rate
:
Wi-Fi 7 2 × 2
:
2.4 GHz : 688 Mbps (theoretical)
:
5 GHz : 2882 Mbps (theoretical)
:
Total theoretical negotiated rate : 3570 Mbps
Master Router
:
2.4G : 2 antennas; 5G : 4 antennas
Extender
:
2.4G : 2 antennas; 5G : 4 antennas
Master Router
:
10/100/1000 M/2500 M adaptive rate Network Port × 2 (Adaptive WAN and LAN interfaces)
Extender
:
10/100/1000 M adaptive rate Network Port × 1
:
Master Router and Extender
Internal storage (ROM)
:
128 MB
Operation memory (RAM)
:
512 MB
Master Router and Extender
:
Maximum power consumption : 24 W
Working voltage
:
DC 12V 2A
Firewall security
:
Supported
HUAWEI HomeSec®
:
Supported
:
(*HUAWEI HomeSec® security protection: Wi-Fi brute force attack prevention)
Parental Control
:
Supported
:
(*Add Internet time, payment, gaming, video, and social network access restrictions, and block access to unsecure sites for a safer online environment.)
Wi-Fi Security
:
Supported
:
(WPA2-PSK, WPA/WPA2-PSK, WPA2-PSK/WPA3-SAE, and blocklist/trustlist)
Storage humidity
:
5% ~ 95%
Storage temperature
:
-40ºC ~ 70ºC
Operating temperature
:
0ºC ~ 40ºC
Operating humidity
:
5% ~ 95% , non-condensing
:
2.4G channel : 1-13
:
5G channel : 36-64 and 100-140 in countries and areas using the CE standards.
HUAWEI AI Life
:
iOS/Android/HarmonyOS
:
Power adapter × 2
:
QSG (with warranty card) × 1
:
Master Router × 1
:
Extender × 1
:
Ethernet cable × 1
Source: consumer.huawei.com
